Technical Specifications

---

Type                                   Mid-longitudinal 90 ° turbocharged petrol V8

Capacity                            2.9 litre / 2936 cc (179.166 cu in)

Bore / stroke                     82 × 69.5 mm / 3.23 × 2.74 in

Bore / stroke ratio            1.18

Engine code                      F120 A000

Valve gear                         Double overhead camshaft, 32 valves total
Maximum power output   478 PS (471 bhp) (351kW) at 7000 rpm

Power per litre                   160.4 bhp/litre / 2.63 bhp/cu in

Maximum torque               577 Nm (426 ft.lb) (58.8 kgm) at 4000 rpm

Specific torque                   196.53 Nm/litre / 2.38 ft·lb/cu^3

Compression ratio             7.7:1

Fuel system                        Marelli Weber fuel injection

Engine coolant                   Water

No. of intercoolers             2

Frame                                 Tubular steel and composites

Drive                                   Rear wheel drive

Steering                              Rack and pinion

Gearbox                              5 speed manual

Turning circle                     11.60 m

Front wheel size                 8 x 17

Rear wheel size                  13 x 17

Front tyres                          245/40 ZR 17

Rear tyres                           335/35 ZR 17

Type                                     Two-seater berlinetta

Wheelbase                          2451 mm

Length                                 4430 mm

Width                                   1989 mm

Height                                  1130 mm

Ground clearance               125 mm

Kerb weight                         1100 kg / 2425 lb

Fuel tank capacity              120 litres

Production start                    1987

Production end                     1992

Production total                    1311

Production location              Maranello
